23063L-003 Rev. 1 12/6/04 R110Xi/R170Xi User Guide 53
FORMAT PREFIX
Format Prefix Character
The format prefix is a two-digit hex value used as a parameter place marker in
ZPL/ZPL II format instructions. The printer looks for this hex character to indicate
the start of a ZPL/ZPL II format instruction. See the ZPL II Programming Guide
Vol u me I for more information.
Note • Do not use the same hex value for the control, format, and delimiter
character. The printer must see different characters to work properly.
1. Press the left oval to move to the next digit position.
2. Press the right oval to increase the value of the digit.
Default: 5E (caret)
Range: 00 to FF
DELIMITER CHAR
Delimiter Character
The delimiter character is a two-digit hex value used as a parameter place marker in
ZPL/ZPL II format instructions. See the ZPL II Programming Guide Volume I for
more information.
Note • Do not use the same hex value for the control, format, and delimiter
character. The printer must see different characters to work properly.
1. Press the left oval to move to the next digit position.
2. Press the right oval to increase the value of the digit.
Default: 2C (comma)
Range: 00 to FF
ZPL MODE
Selecting ZPL Mode
The printer remains in the selected mode until it is changed by this front panel
instruction or by using a ZPL/ZPL II command. The printer accepts label formats
written in either ZPL or ZPL II, eliminating the need to rewrite any ZPL formats
that already exist. See the ZPL II Programming Guide for more information on the
differences between ZPL and ZPL II.
• Press the right or left oval to display other choices.
Default: ZPL II
Selections: ZPL II, ZPL
Table 7 • Standard LCD Displays (Page 10 of 16)
