5 - 10 TC56 User Guide for Android Version 6.0.1
1. Ensure that NFC is enabled on the TC56.
2. Ensure that Bluetooth is enabled on both devices.
3. Ensure that the Bluetooth device to discover is in discoverable mode.
4. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
5. Place the RS6000 in Human Interface Device (HID) mode. If the RS6000 is already in HID mode, skip to step
5.
a. Remove the battery from the RS6000.
b. Press and hold the Restore key.
c. Install the battery onto the RS6000.
d. Keep holding the Restore key for about five seconds until a chirp is heard and the Scan LEDs flash green.
e. Scan the bar code below to place the RS6000 in HID mode.
Figure 5-17 Bluetooth HID Bar Code
6. Remove the battery from the RS6000.
7. Re-install the battery into the RS6000.
8. Align the NFC icon on the RS6000 with the NFC icon on the TC56.
The Status LED blinks blue indicating that the RS6000 is attempting to establish connection with the TC56.
When connection is established, the Status LED turns off and the RS6000 emits a single string of low/high
beeps.
A notification appears on the TC56 screen.
The icon appears in the Status bar.
Figure 5-18 Align NFC Antennas
NOTE RS6000 only.
