Accessories 7 - 15
5-Slot Ethernet Cradle
The 5-Slot Ethernet Cradle:
• Provides 5.0 VDC power for operating the device.
• Connects the device (up to five) to an Ethernet network.
• Simultaneously charges up to five TC56s.
Figure 7-11 5-Slot Ethernet Cradle
Charging the TC56
To charge a device:
1. Insert the TC56 into a slot to begin charging.
CAUTION Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page
8-2.
1000 LED
TC56 Charging Slot
100/100 LED
NOTE If the device has a Rugged Boot, remove the cup insert before inserting the device. See TC56 Touch
Computer Integrator Guide for Android Version 6.0.1 for details.
