1 - 16 TC56 User Guide for Android Version 6.0.1
10. Remove the SIM card.
11. Place the new SIM card into the card holder with contacts facing down.
12. Close the SIM card holder.
13. Slide the SIM card holder door to the lock position.
14. Replace the access door.
Figure 1-26 Replace Access Door
15. Insert the battery, bottom first, into the battery compartment in the back of the TC56.
16. Press the battery down until the battery release latch snaps into place.
17. Replace the hand strap, if required.
18. Press and hold the Power button to turn on the TC56.
Accessing Device Settings
Throughout this guide, the user can access device:
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. On the Home screen, touch > .
CAUTION Access door must be replaced and securely seated to ensure proper device sealing.

Table of Contents

Other manuals for Zebra TC56

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra TC56 and is the answer not in the manual?

Zebra TC56 Specifications

General IconGeneral
Display diagonal5 \
Touch technologyDual-touch
Touchscreen typeCapacitive
Display resolution1280 x 720 pixels
Flash memory0.016 GB
Internal memory0.002 GB
Internal memory typeRAM
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
Maximum memory card size128 GB
Processor familyQualcomm
Processor frequency1.8 GHz
Operating system version6.0
Operating system installedAndroid
RFID reader-
CertificationWFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product colorBlack, Silver
Linear (1D) barcodes supportedCode 39
International Protection (IP) codeIP67
Battery capacity4300 mAh
Data networkCDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.1
GSM bands supported850, 900, 1800, 1900 MHz
Security algorithmsAES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported850, 1900 MHz
Second cameraNo
Rear camera resolution (numeric)13 MP
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Weight and Dimensions IconWeight and Dimensions
Depth155 mm
Width75.5 mm
Height18.6 mm
Weight249 g
