Getting Started 1 - 15
4. If hand strap is attached, slide the hand strap clip up toward the top of the TC56 and then lift.
5. Press the two battery latches in.
6. Lift the battery from the TC56.
7. Lift the access door.
Figure 1-23 Remove Access Door
8. Slide the SIM card door to the unlock position.
Figure 1-24 Unlock SIM Card Door
9. Lift the SIM card holder door.
Figure 1-25 Lift the SIM Card Door
