7 - 28 TC56 User Guide for Android Version 6.0.1
Figure 7-32 Cable Installation
3. Align the cable cup with the bottom of the device.
4. Press the device into the cable cup until it securely in place.
USB Communication
To connect the device to a host computer:
1. Connect the Rugged Charge/USB Cable to the TC56.
2. Connect the USB connector of the cable to a host computer.
Figure 7-33 Rugged Charge/USB Cable to Host Computer
Charging the Device
To charge the device using the Rugged Charge/USB Cable:
1. Connect the Rugged Charge/USB Cable to the TC56.
2. Connect the USB connector of the power supply.
