xiv TC56 User Guide for Android Version 6.0.1
Software Versions
To determine the current software versions, swipe down with two fingers from the status bar to open the quick
access panel and then touch .
Touch About phone.
• Model number- Displays the model number.
• Android version - Displays the operating system version.
• Kernel version - Displays the kernel version number.
• Build number - Displays the software build number.
• Serial number - Displays the serial number.
To determine the device serial number, touch About phone > Status.
• Serial number - Displays the serial number.
Chapter Descriptions
Topics covered in this guide are as follows:
• Chapter 1, Getting Started provides information on getting the TC56 up and running for the first time.
• Chapter 2, Using the TC56 provides information for operating the TC56.
• Chapter 3, Calls provides instructions for making phone calls.
• Chapter 4, Applications provides information on using applications installed on the TC56.
• Chapter 5, Data Capture provides information for capturing bar code data using the imager.
• Chapter 6, Wireless provides information on the various wireless options.
• Chapter 7, Accessories provides information for using the accessories for the TC56.
Configuration Radios Display Memory
Data Capture
Options
Operating
System
TC56CJ WLAN: 802.11
a/b/g/n/d/h/i/k/r
WPAN: Bluetooth
v4.1 Low Energy
WWAN: HSPA+/
LTE/CDMA
5.0” High
Definition (1280 x
720) LCD
2 GB RAM / 16
GB Flash or 4 GB
RAM / 32 GB
Flash
2D imager
(SE-4710) and
integrated NFC
Android Open
Source Project
(AOSP) 6.0.1 or
Google™ Mobile
Services (GMS)
6.0.1.
TC56DJ WLAN: 802.11
a/b/g/n/d/h/i/k/r
WPAN: Bluetooth
v4.1 Low Energy
WWAN: HSPA+/
LTE
5.0” High
Definition (1280 x
720) LCD
2 GB RAM / 16
GB Flash or 4 GB
RAM / 32 GB
Flash
2D imager
(SE-4710) and
integrated NFC
Android Open
Source Project
(AOSP) 6.0.1 or
Google™ Mobile
Services (GMS)
6.0.1.

Zebra TC56 Specifications

General

Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	0.016 GB
Internal memory	0.002 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Processor family	Qualcomm
Processor frequency	1.8 GHz
Operating system version	6.0
Operating system installed	Android
RFID reader	-
Certification	WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Battery capacity	4300 mAh
Data network	CDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported	850, 1900 MHz
Second camera	No
Rear camera resolution (numeric)	13 MP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Height	18.6 mm
Weight	249 g
