1 - 12 TC56 User Guide for Android Version 6.0.1
5. If hand strap is attached, remove hand strap.
6. Press the two battery latches in.
Figure 1-18 Press Battery Latches
7. Lift the battery from the TC56.
Figure 1-19 Lift the Battery
8. Insert the replacement battery, bottom first, into the battery compartment in the back of the TC56.
9. Press the battery down until the battery release latch snaps into place.
CAUTION Replace the battery within 90 seconds. After 90 seconds the device reboots and data may be lost.
