Zebra TC57 - Inserting a Device with Rugged Boot into Cradle

Accessories
184
1. Insert the device into a slot to begin charging.
Figure 149 TC57 Battery Charging
2. Ensure the device is seated properly.
NOTE: See the TC57 Touch Computer Integrator Guide for Android 8.1.0 Oreo for information on installing the 4-Slot Battery
Charger onto the cradle.
Inserting a Device with Rugged Boot into Cradle
Each cradle cup has an insert that must be removed prior to inserting the device with Rugged Boot. Remove
the insert and then insert the device into the cup.
Figure 150 Remove Insert from Cup
