Accessories
205
Trigger Handle
NOTE: The Rugged Boot is required to install the Trigger Handle onto the device. Trigger Handle (p/n TRG-TC51-SNP1-01)
does not contain the Rugged Boot and must be purchased separately. Trigger Handle Kit (p/n TRG-TC51-TRG1-01)
contains the Rugged Boot.
The Trigger Handle adds a gun-style handle with a scanning trigger to the device. It increases comfort when
using the device in scan-intensive applications for extended periods of time.
Figure 180 Trigger Handle
Installing the Rugged Boot
NOTE: If a Hand Strap is attached to the Rugged Boot, remove prior to installing onto device.
To install the Rugged Boot:
Trigger
Release
Latch
Lanyard
Mount
Flange
