Accessories
195
2.5 mm Audio Adapter
NOTE: The Audio Adapter is available for the device standard configuration.
The 2.5 mm Audio Adapter plugs into the device and connects to a wired headset with a 2.5 mm plug.
To attach a 2.5 mm headset:
1. Open the headset jack cover.
2. Insert the 2.5 mm Audio Adapter plug into the headset jack.
Figure 164 Audio Adapter Installation
3. Insert the 2.5 mm headset plug into the jack on the Audio Adapter.
Figure 165 Connect Headset to Audio Adapter
CAUTION: After removing headset, headset jack cover must be replaced and securely seated to ensure proper device
sealing.
