Zebra TC57 - Connecting to TC57 with Rugged Boot

Accessories
199
2. Rotate the device into the cup.
Figure 170 Rotate Device into Cable Cup
Connecting to TC57 with Rugged Boot
To connect the Rugged Charge/USB Cable to a device with a Rugged Boot:
1. Using thumb and index finger, squeeze the sides of the cup in.
Figure 171 Remove Cable Cup Insert
