Applications
97
NOTE: See the device Integrator Guide for Android Version 8.1 for information on DataWedge configuration.See Da-
taWedge on page 150
for more information.
Scanner Selection
To select a scanner, touch > Settings > Scanner selection.
See Data Capture for more information.
Either press the programmable button or touch the yellow scan button to capture data. The data appears in the
text field below the yellow button.Press the scanner trigger button or touch the on-screen yellow scan button to
capture data. The data appears in the text field below the yellow button.
Data Capture The data capture function is through the internal imager.
Data Capture Indicates a USB scanner is connected to the device.
Indicates a USB scanner is not connected to the device.
An RS507 or RS6000 Bluetooth imagerBluetooth scanner is connected.
An RS507 or RS6000 Bluetooth imagerBluetooth scanner is not
connected.
The data capture function is through the rear camera.
Scan Mode Imager is in picklist mode. Touch to change to normal scan mode.
Imager is in normal scan mode. Touch to change to picklist mode.
Opens a menu to view the application information or to set the
application DataWedge profile.
Table 9 DataWedge Demonstration Icons (Continued)
Icon Description
To Next Page
