Technical Specifications
220
Buttons Programmable back button; dual dedicated scan buttons;
dedicated push-to-talk button, and volume up/down buttons
Performance Characteristics
CPU Qualcomm Snapdragon 660 octa-core, 2.2 GHz.
Operating System Android 8.1.0 Oreo with Zebra’s Restricted Mode for control over
GMS and other services.
Memory 4 GB RAM/32 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Relative Humidity Operating: 5 to 95% non-condensing
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Humidity 5 to 85% non-condensing
Drop Specification Multiple 1.2 m (4 ft.) to tile over concrete over -10°C to 50°C
(14°F to 122°F).
Multiple 1.8 m (6 ft.) drops to concrete with Rugged Boot per Mil
Std 810 G.
Tumble 500 0.5 m (1.6 ft.) tumbles; meets and exceeds IEC tumble
specifications
Sealing IP67 and IP65 per applicable IEC sealing specifications
Electrostatic Discharge (ESD) ±15 kVDC air discharge, ±8 kVDC direct discharge, ± 8 kVDC
indirect discharge
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to
2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock -40°C to 70°C (-40°F to 158°F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer with MEMS Gyro
Light Sensor Automatically adjusts display backlight brightness
Proximity Sensor Automatically detects when the user places the handset against
head during a phone call to disable display output and touch
input.
Pressure Sensor Automatically detects altitude information for locationing.
Magnetometer eCompass automatically detects direction and orientation.
Table 17 TC57 Technical Specifications (Continued)
Item Description
