115
Printer Configuration and Adjustment
Adjust Printer Settings
5/22/17 ZT600 Series™ User Guide P1088680-001
SETTINGS > LABEL LENGTH MAX
Set a maximum label length that is at least 1.0 in. (25.4 mm) greater than the actual label
length plus the interlabel gap. If you set this value too small, the printer assumes that
continuous media is loaded and cannot calibrate.
SETTINGS
—
DARKNESS
—
PRINT SPEED
—
MEDIA TYPE
—
PRINT METHOD
—
TEAR OFF
—
PRINT WIDTH
—
PRINT MODE
—
LABEL TOP
—
LEFT POSITION
—
REPRINT MODE
—
LABEL LENGTH MAX
—
COVER OPEN LIGHT
—
MEDIA PATH LIGHTS
—
RIBBON PATH LIGHTS
—
LANGUAGE
Accepted values: 0 to the maximum label length supported by the printer
For example, if the label length is 6.0 inches (152 mm) including the interlabel
gap, set the parameter for at least 7.0 inches (178 mm).
2
1
Label length (including interlabel gap)
2
Interlabel gap
3
Minimum label length value
1
3
