ZOE PPM3 - Page 206

24-8 Nightingale PPM3 User's Guide April 2019
Technical Data
Measurement Accuracy for Gas
Mixture
Meets ISO 21647 Clause 51.101.3 (Tables 101 and 103):
± (volume fraction of 0.43% + 8% of gas level)
Measurement Accuracy in the
Presence of Interfering Gases
Meets ISO 21647 Clause 101.1 (Tables 101 and 105):
± (volume fraction of 0.43% + 8% of gas level)
Masimo ISA
TM
CO
2
/ Capnography
Method
Sidestream (Non-dispersive IR)
Units
mmHg
Parameters
ETCO
2
, FICO
2
, RRc
CO
2
Measurement Range
ETCO
2
& FICO
2
: 0 to 150 mmHg
CO
2
Measurement Accuracy
As measured with dry single gases:
0 to 15 vol%: ±(0.2 vol% + 2% of reading)
15 to 25 vol%: unspecified
CO
2
Resolution
1 mmHg
RRc (Resp. Rate) Measurement
Range
0 to 150 ± 1 bpm
RRc Resolution
1 bpm
Barometric Pressure Range
525 to 1200 hPa
Barometric Pressure
Compensation
Automatic
Report Interval
Per breath
Flow Rate
50 ± 10 sml/min
Warm-up Time Required to
Meet Accuracy Specifications
< 10 seconds (concentrations reported and full accuracy)
Total System Response Time
< 3 seconds (with 2m Nomoline sampling line)
Drift of Measurement Accuracy
Complies with EN ISO 21647:2004 standard
Measurement Accuracy for Gas
Mixture
Complies with EN ISO 21647:2004 standard
Measurement Accuracy in the
Presence of Interfering Gases
Complies with EN ISO 21647:2004 standard
Masimo IRMA
TM
CO
2
/ Capnography
Method
Mainstream
