April 2019 Nightingale PPM3 User's Guide 24-9
Technical Data
Units
mmHg
Parameters
ETCO
2
, FICO
2
, RRc
CO
2
Measurement Range
ETCO
2
& FICO
2
: 0 to 150 mmHg
CO
2
Measurement Accuracy
Dry single gases at 22 ± 5°C and 1013 ± 40 hPa
0 to 15 vol%: ±(0.2 vol% + 2% of reading)
15 to 25 vol%: unspecified
All conditions
±(0.3 kPa + 4% of reading)
CO
2
Resolution
1 mmHg
RRc (Resp. Rate) Measurement
Range
0 to 150 bpm. RRc is displayed after 3 breaths and the average
value is updated every breath.
RRc Resolution
1 bpm
Barometric Pressure Range
525 to 1200 hPa
Barometric Pressure
Compensation
Automatic
Report Interval
Per breath
Warm-up Time Required to
Meet Accuracy Specifications
< 10 seconds (concentrations reported and full accuracy)
Total System Response Time
< 1 second
Drift of Measurement Accuracy
Complies with EN ISO 21647:2004 standard
Measurement Accuracy for Gas
Mixture
Complies with EN ISO 21647:2004 standard
Measurement Accuracy in the
Presence of Interfering Gases
Complies with EN ISO 21647:2004 standard
Invasive Blood Pressure
Transducer Type
Strain gauge
Transducer Excitation Voltage
5.00 VDC ± 1 %
Frequency Response
0-12 Hz
Measurement Units
mmHg
Parameters
Diastolic, Systolic, Mean for all except Mean-only for CVP
Measurement Range
-50 to 300 mmHg
Measurement Accuracy
± 1 mmHg or ± 1 %, whichever greater
