24-10 Nightingale PPM3 User's Guide April 2019

Technical Data

IBP Resolution

1 mmHg

Pulse Rate Measurement Range

30 - 250 bpm

Pulse Rate Accuracy

± 2 bpm or ±2 %, whichever greater

Numeric Update Rate

Every 3 seconds

Temperature

Compatibility

YSI 400-series probes

Measurement Mode

Direct (as defined in ISO 80601-2-56)

Input Connector

2-pin connector

Display Units

°F and °C (user-selectable)

Measurement Resolution

0.1 °F (0.1 °C)

Measurement Range

41.0 to 122.0 °F (5.0 to 50.0 °C)

Measurement Accuracy

±0.2 °F (±0.1 °C) plus probe tolerance

Transient Response

Within 30 seconds from 25 to 27 °C
