Service Kit Installation Procedures
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 4–53
3 Place the replacement cover over ventilator, then
align the cover with the handle, air intake housing
and dovetail mounting studs.
Insert and tighten the two 10-32 Keps nuts
(provided in the kit) and the four 6-32 x 2” screws.
4 Tighten the four 8-32 x 3 screws on the outer air
intake.
5
Re-certify the ventilator using the RCS.
Step Action
