Maintenance Schedule & Procedures
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 3–15
Disk Filter Replacement (Annual)
The Fresh Gas/Emergency Air Intake Disk Filter is located behind the Removable Foam Filter. This filter provides a
second level of filtration to the ambient air that is delivered to the patient. This filter must be checked periodically
and replaced when necessary. The device triggers an alarm when the combination of Removable Foam Filter and
Fresh Gas/Emergency Air Intake Disk Filter become dirty. This alarm signifies that the device is still able to deliver
the correct tidal volume but one or more of its filters need replacement. The Fresh Gas/Emergency Air Intake Disk
Filter can be visually inspected after the Fresh Gas Intake assembly is removed. If the filter appears discolored it
must be replaced.
Required Annually
Disk Filter Replacement Instructions
Scan Or Click To Watch Video
Required Equipment:
• 1 Year Service Kit (See Service
Kits Chapter)
• Tweezers/hemostats
• #2 Phillips Head Screwdriver
• Torque Driver
Step Removal Instructions
1.
To begin place the ventilator on it’s side so that the fresh gas intake faces up. Using a #2
Phillips head screwdriver loosen the four Phillips 8-32 flathead screws securing the fresh
gas intake to the chassis.
2. Lift and remove the fresh gas intake.
3. Using tweezers, grasp the disk filter and lift to remove it from the BV filter holder.
Step Replacement Instructions
1. Using tweezers lower the disk filter into the BV filter holder, ensuring it is properly seated.
2.
Insert the fresh gas intake into the device, making sure that its alignment pin mates. The
O-Ring and gasket should be checked and replaced if damaged.
3.
Using a torque driver set to 14 in lbs/1.58 newton meter replace the four 8-32 flathead
screws.
