Service Kit Installation Procedures
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 4–73
Oxygen Inlet Fitting Service Kit Installation Instructions
Required Tools
• Torque driver with #1 and #2 Phillips bits
Kit Contents
Quantity Description Depiction
1 Oxygen inlet fitting with filter, cap and chain
3 Screw, Phillips, Flat Head, 8-32 x 7/16, ZP
1 O-Ring, Black, Neoprene,
1/2"O.D.x 3/8"I.D. (Nominal)
3 O-Ring, Buna-N
5/16 OD X 3/16
