Ventilator & Calibration Troubleshooting
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 6–51
Low Priority Service Codes - Version 4
Service Code Associated Alarm Name/Description Service Kit/Resolution
3001
Self Check Fault
Alarm triggers when the compressor fails to operate or fails to provide the
flow required to deliver a breath within ± 10% of the current settings, high
pressure O
2
is available to provide ventilation and the user has set the FIO
2
to 100%.
Smart Pneumatic Module/
Vent Assembly Service Kit
3002
Self Check Fault
Alarm triggers when communication between the compressor controller
and the SPM is lost, high pressure O
2
is available to provide ventilation and
the user has set the FIO
2
to 100%.
Smart Pneumatic Module/
Vent Assembly Service Kit
3011
Self Check Fault
Alarm triggers when the signal to the O
2
valve is outside of the calibration
range for the required flow rate, the compressor is available to provide
ventilation and the user has acknowledged that ventilation is being
provided using the compressor by setting the FIO
2
to 21%.
Smart Pneumatic Module/
Vent Assembly Service Kit
3012
Self Check Fault
Alarm triggers when communication between the O
2
valve and the SPM is
lost, the compressor is available to provide ventilation and the user has set
the FIO
2
to 21%.
Smart Pneumatic Module/
Vent Assembly Service Kit
3030
Gas Intake Fault
Alarm triggers when the Fresh Gas/Emergency Air Inlet is blocked so that
the compressor is not able to deliver breaths within ± 10% of the current
settings, high pressure O
2
is available to support ventilation and the user
has set the FIO
2
to 100%.
Smart Pneumatic Module/
Vent Assembly Service Kit
3031
Intake Restricted
Alarm triggers when the Fresh Gas/Emergency Air Inlet is blocked but is still
capable of delivering breaths within ± 10% of the current settings. This
could be caused by an external blockage or a dirty/wet external or internal
filter.
Smart Pneumatic Module/
Vent Assembly Service Kit
3032
Self Check Fault
Alarm triggers when communication between the
Fresh Gas/Emergency Air Inlet pressure sensor is lost.
Smart Pneumatic Module/
Vent Assembly Service Kit
3041
High O2 Supply Fault
Alarm triggers when the high pressure O
2
supply is ≥75 psig (517 kPa) and <
80 psig (552 kPa).
Lower oxygen input pressure
3073
Tubing Compliance Fault
Alarm is triggered when the tubing compliance correction shows that it
is greater than the set tidal volume, indicating that the patient may not
be receiving the appropriate tidal volume.
Check internal/external
tubing connections
