Device Overview & Architecture
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 2–3
Main Features
Figure 2-1 shows the ventilator’s main features.
Figure 2-1 Main Features
Item Location Description
Oxygen Inlet Top Enables connection to an external high pressure oxygen source.
Status Indicator LED Array Top Lights to indicate ventilator status and a visible alarm indicator.
External Power Input Connector Top Enables connection to an external power source.
USB Connector Top
Enables connection to a USB compatible device for servicing the
ventilator.
