ZOLL EMV+ - Bulk Supplies

Service Kit Installation Procedures
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 4–11
Bulk Supplies
Refer to the table below for a list of supplies to have on hand if regularly servicing 731 series ventilators.
Bulk Supplies - Screws & Nuts
PN Qty Location Type
0163-000460 1 Z-Vent Power Input Plug Hex Socket
Shoulder
346-0632-01 4 Connector Panel to Flow Manifold Keps Nuts KEPS Nut
346-1032-01 2 Back Cover Keps Nut KEPS Nut
355-0632-04 4 Dovetail Mounting bracket (Left and Right sides) Flat Head
355-0832-04 2 Chassis to SPM bottom Flat Head
357-0440-04 4 Power Input to Connector Panel, Dovetail Stiffener Bracket Flat Head
357-0440-20 2 Power Input Assembly w/Spacers Flat Head
357-0632-04 4 Pump Bracket to Chassis Flat Head
357-0632-05-2 2 Back Cover to Dovetail Bracket Flat Head
357-0832-04 3 Connector Panel to Flow Manifold Screws Flat Head
357-0832-07 3 O2 Fitting Flat Head
357-0832-48 4 Fresh Gas Air Intake Assembly Flat Head
358-0440-03 7 USB Cable, Green cap & chain to O2 Fitting, Connector Snap
Cover Assembly to connector panel
Pan Head
358-0440-04 28 Front Case Assembly to Vent Module , Front Bezel, Buzzer,
UIM Adapter Board, CPU to UIM Bracket, PIM board to SPM
Assy, SPM PCB to SPM,Foam Filter Holder Screen to B/V
Holder
Pan Head
358-0440-05 2 USB Connector Plate Pan Head
358-0440-08 4 15mm Compressor Input Port to Compressor Pan Head
358-0440-11 2 O2 Valve Pan Head
358-0440-28 4 Oxygen Inlet Manifold to Mix Manifold Pan Head
358-0632-05 16 Battery Cover, LCD, UIM Stack to Front Case, Batt
Compartment, Inside by Air Intake
Pan Head
358-0632-08 2 B/V Filter Holder Base to Mix Manifold Pan Head
358-0632-24 2 Compressor to Pump Bracket Pan Head
358-0632-32 4 Back Cover Pan Head
358-0632-36 4 Battery Pan Head
360-0440-05 4 Flow Manifold to Compressor Output Hex Socket
360-0632-05 4 Compressor Connector to Mix Manifold Hex socket
