Service Kit Installation Procedures
4–12 www.zoll.com 906-0731-04-01 Rev. C
363-0006-00 2 Masimo Plug (SPO2 Cable) Flat Head
366-0400-05 1 SPO2 PCB to UIM Bracket Self Tapping
376-0007-00 2 BV Holder to Mix Manifold #6 Flat washer
376-0079-00 4 Flow Manifold to Compressor Output #4 Split ring washer
Bulk Supplies - Components
Part Number Qty Part Type Location Picture
340-0106-00 2
O-Ring Compressor
Inlet/Outlet
340-0020-00 1
O-Ring
Snap Cover
340-0113-00 1
O-Ring
Mix Manifold
490-0005-00 1 Leaf Valve BV Filter
Holder Base
