Maintenance Schedule & Procedures
3–14 www.zoll.com 906-0731-04-01 Rev. C
Foam Filter Replacement (Annual)
The Removable Foam Filter is located on the right side of the ventilator. It should be inspected and replaced if
needed every 1,000 hours of operation or more frequently if used in dusty environments.
Required Annually
Foam Filter Replacement Instructions
Scan Or Click To Watch Video
Required Equipment:
• 1 Year Service Kit (See Service
Kits Chapter)
• Tweezers/hemostats
Step Removal Instructions
1.
To begin, using tweezers, reach into the compressor intake housing and grasp the foam
filter.
2. Lift and remove the foam filter.
Step Replacement Instructions
1. Lower the foam filter into the compressor intake housing.
2.
To complete, lightly tap the foam filter into place, allowing it to expand into the fresh gas
intake housing.
