General Information
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 1–5
Power Input Orientation: Locates the DC input
identifying its point of insertion.
Manufacturer: This symbol identifies the name and
address of the manufacturer.
Manufacturer Date: Manufacturer Date Symbol
identifies the device’s date of manufacture.
Refer to instruction manual.
Menu icon. This icon identifies the button that, when
pressed, displays a menu of options that you can select
to configure the ventilator.
High Pressure 02 Connector (Top Faceplate, Note: The
appearance of this label may be different depending
on ventilator age).
Exhalation Valve (Top Faceplate, Note: The
appearance of this label may be different depending
on ventilator age).
Exhaust Do Not Occlude (top faceplate icon).
