Ventilator & Calibration Troubleshooting
6–4 www.zoll.com 906-0731-04-01 Rev. C
Table 1 - Test Sequences RCS 7 RCS RELEASE 7 SEQUENCES
Discrete Test Name Sub System
Incoming System
Testing
Complete
Calibration
Outgoing
System Testing
Comm RAM and Bootloader Check Front Case – CPU
● ●
Power Switch Check Front Case – I/O & UIM Board
● ●
EMV Self Check Front Case – CPU
● ●
LCD Contrast Set
Front Case – LCD, UIM & CPU
Board
● ●
LCD Visual Inspection Front Case – LCD
● ●
Button Check Front Case – I/O & UIM Board
● ●
Total Power Failure Alarm Check Front Case – UIM
● ●
LED Check Front Case – I/O, UIM & CPU
● ●
Encoder Check Front Case – I/O
● ●
Buzzer Check Front Case – UIM
● ●
Li-Ion Battery Check Battery
● ●
Pulse Oximeter SpO2 and Heart Rate Pulse Oximeter
● ●
SPM Communication SPM ●
SPM Self Check SPM
● ● ●
SPM Blink SPM – Board
● ●
TSI Calibration Check Test Station
● ● ●
Calibration Check Barometric Pressure SPM – Board
● ●
Compressor Calibration SPM – Compressor System
●
Incoming Calibration Check Compressor
System
SPM – Compressor System
●
Calibration Check Compressor System SPM – Compressor System
●
Airway Pressure Calibration SPM – Board
●
Incoming Calibration Check Airway
Pressure
SPM
●
Calibration Check Airway Pressure SPM
●
O2 Kickstart Calibration SPM – O2 System
●
Calibration Check O2 Kickstart SPM – O2 System
● ● ●
O2 Flow Calibration SPM – O2 System
●
Incoming Calibration Check O2 System SPM – O2 System
●
Calibration Check O2 System SPM – O2 System
●
O2 Leak Filter and Pressure Cal. Check SPM – Manifold and Board
● ●
Manifold Leak Check SPM – Manifold
● ●
Exhalation Backup and Autocal Valve SPM – Board
● ●
Compressor Bypass Protection SPM – Compressor
● ●
Breath Performance Check SPM – O2 & Compressor Systems
●
Date and Time Set SPM – Board
●
Date and Time Check SPM – Board
●
Download Calibration Tables Test Station
●
Verify UUT and Reference Device Test Station
● ● ●
Conditional PM Due Reset Test Station/Device
●
