Device Overview & Architecture
2–6 www.zoll.com 906-0731-04-01 Rev. C
Indicators
The ventilator’s indicators consist of the following:
Accept/Select button
The Accept/Select button allows the user to accept parameter value settings,
acknowledge popup messages, and accept menu choices
Manual Breath Button/
Plateau Pressure
Enables the user to deliver a manual breath and measure Plateau Pressure
Note: Plateau Pressure is an optional ventilator control.
Indicator Description
LCD Display Displays settings, patient data, and alarm information.
LED Array Indicates operational status (Red, Yellow, or Green).
