Device Overview & Architecture
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 2–9
Connector Panel Assembly
The Connector Panel Assembly is a user interface that allows for connection of the patient circuit's main hose,
patient airway monitoring hose and exhalation drive hose. The panel also has the high pressure oxygen connection
attached. The panel is the pathway for the exhalation valve's pressure to exhaust to atmosphere. Power input and
power filtering are connected to the control panel. Located to the front and right of the Control Panel is the USB port
for calibration and diagnostics and the pulse oximeter connector.
