Service Kit Installation Procedures
4–2 www.zoll.com 906-0731-04-01 Rev. C
CAUTION
Replacement of the Oxygen Valve Assembly requires the handling of Oxygen Clean Parts. When handling any
metal components within the ventilator which are responsible for transporting oxygen, take the following
precautions:
• Never touch the components with your bare hands as oils and residue may contaminate the
component.
• Keep all Oxygen Clean parts in their protective packaging prior to installation.
• Do not keep sources of contaminate on the workbench such as soldering material.
• If an oxygen clean part becomes contaminated, replace the part and do not attempt to clean it.
CAUTION
Follow torque specifications listed to avoid damage to the device. Refer to the Torque Specification Guide section
of this chapter.
WARNING:
For Service Kit installations requiring electrical safety testing, electrical safety testing should NOT be
performed in or around ESD testing areas. ESD protocols (methods) should NOT be enforced during
electrical safety testing, since they could cause a hazardous condition for equipment and test
operators.
WARNING:
Service kit installations should be done in an ESD controlled environment.
Remove all jewelry and keep liquids away from the ventilator when servicing it. Always safeguard your
personal well-being when troubleshooting electronic circuitry.
Make sure to take the necessary precautions when working with static sensitive units. For example,
you must wear a conductive wrist strap (which touches your skin) connected to a grounding mat and
to the earth ground.
NOTE:
Screws are coated with anti-vibration compound. When reusing screws clean, then reapply the anti-vibration
compound (Part No. 602-0006-00). Some kits require the RTV silicone sealant be reapplied (Part No. 602-0001-00)
