Service Kit Installation Procedures
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 4–17
USB Connector Plate 2 4-40 X 5/16" 2.5 0.3
LCD 4 6-32 X 5/16"
Screws, 6-32 Keps
Nuts
9 1.0
CPU to UIM Bracket 4 4-40 X 1/4" 4.5 0.5
SPO2 PCB to UIM
Bracket
1 #4-5/16" Tap @ 5 then loosen
and re-tighten to 3.5
0.4
USB Connector Cover 1 4-40 X 3/16” 3.5 0.4
CHASSIS ASSEMBLY
Inside by Air Intake 2 6-32 X 5/16" 9 1.0
Chassis to SPM bottom 2 8-32 X 1/4" 19 2.0
Chassis to dovetail
mounting bracket
2 6-32 X 1/4" 3.5 0.4
Power Input Assembly
w/Spacers
2 4-40 X 1.25" 3.5 0.4
DOVETAIL MOUNTING BRACKET
Dovetail Mounting
Bracket Left and Right
sides
4 6-32 X 1/4" 3.5 0.4
To dovetail stiffener
bracket
2 4-40 X 1/4" 5 0.6
SPM
PIM board to SPM Assy 5 4-40 X 1/4" 3.5 0.4
Fresh Gas Air Intake
Assembly
4 8-32 X 3" 14 1.6
B/V Filter Holder Base to
Mix Manifold
2 6-32 X 1/2" 5 0.6
Foam Filter Holder
Screen to B/V Holder
2 4-40 X 1/4" 5 0.6
Green cap & chain to O2
Fitting
1 4-40 X 3/16 5 0.6
O2 Fitting 3 8-32 X 7/16 19 2.0
Gas Output Fitting N/A N/A 75 8.5
Screw/Nut/Component Quantity Screw/Nut Size
Maximum Torque
(in-lb)
Maximum Torque
(Nm)
