Service Kit Installation Procedures
4–40 www.zoll.com 906-0731-04-01 Rev. C
2 Remove backing from the bumper feet, then place
one at each corner of the battery case bottom
cover.
3 Rotate cover to align with the battery
compartment, then insert and tighten the four 6-
32 x 5/16 screws.
4 Re-certify the ventilator using the RCS.
Step Action
