Chapter14EthernetOAMConguration
St-
ep
CommandFunction
3
ZXR10(config)#clearethernet-oam{all|statistic}
Thisclearscongurationor
statisticsdata.
Selectalltoclearall
ethernet-oamconguration.
Selectstatisticforclearing
allstatisticinformationbut
reservingconguration.
InstanceConfiguration
AsshowninFigure28,runethernet-oamonR1andR2.R1port
isgei_1/1,R2portisgei_1/2.
FIGURE28802.3AHINSTANCECONFIGURATION
Congurationofremotediscovery
CongurationofR1:
ZXR10(config)#setethernet-oamen
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#setethernet-oamenable
ZXR10(config-gei_1/1)#setethernet-oamperiod10timeout3
modepassive
CongurationofR2:
ZXR10(config)#setethernet-oamenable
ZXR10(config)#interfacegei_1/2ZXR10(config-gei_1/2)#setethernet-oamen
ZXR10(config-gei_1/2)#setethernet-oamenable
ZXR10(config-gei_1/2)#setethernet-oamperiod10timeout3modeactive
Whendiscoveringsucess,promptETH-OAMgei_1/2discovery
processissuccessful.
Whenfailing,promptETH-OAMgei_1/2isinformedofremotelink
fault.
ETH-OAM:gei_1/2isinformedofremoteunrecoverablefailure.
Whendiscoveringsucess,thediscoveryinformationshowedbyR2
isasfollows:
ZXR10(config)#showethernet-oamgei_1/2discovery
PortId2:ethernetoamenabled
LocalDTE
-----------
Config:
Mode:active
Period:10*100(ms)
LinkTimeOut:3(s)
Unidirection:nonsupport
