ZXR105900ESeriesUserManual(EthernetSwitchingVolume)
ConfiguringOne-WayPVLAN
ToconguretoforbiduplinkportofSVLANbasedonACLtoforward
datatoloopbackport,usethefollowingcommands.
St-
ep
CommandFunction
1
ZXR10(config)#vlanprivate-map-unidirectional
session-id<id>source<port-list>destination
<port-list>
Thisconguresone-way
PVLANsourceportand
destinationport.
2
ZXR10(config)#novlanprivate-map-unidirectional
session-id<id>
Thiscancelsone-wayPVLAN
conguration.
3
ZXR10(config)#showvlanprivate-map-unidirectio
nal
Thisdisplaystheconguration
informationofone-way
PVLAN.
Note:
1.Uplinkdatapacketisforwardedbycustomerportandbroad-
castinSPVLANafterloopedbyloopbackport.Topreventcus-
tomerportfromreceivingdatamessageloopedbyloopback
port,generally,congureaone-wayPVLANdatawhosesource
portisloopbackportanddestinationportiscustomerport.
2.Downlinkdatapacketisforwardeddirectlytocustomerport
informationbyuplinkport,needn'tbeforwardedtoloopback
port.Toavoidthatthedatapacketthatuplinkportforwards
toloopbackportloopsandisforwardedtouplinkportagain,
mustcongureaone-wayPVLANdatawhosesourceportis
uplinkportanddestinationportisloopbackport.
Example
Thisexampleshowshowtocongureone-wayPVLAN.
ZXR10(config)#vlanprivate-map-unidirectionalsession-id1
sourcegei_1/3-4destinationgei_1/2
ZXR10(config)#vlanprivate-map-unidirectionalsession-id2
sourcegei_1/2destinationgei_1/1
ConfiguringZESR
RefertoZESRcongurationchapter .
ConfigurationExample
1.Conguregei_1/1ascustomerportontheswitch,theCVID
whichreceivesdatapacketisVLAN10,conguregei_1/3/and
gei_1/4asuplinkport,theSPVIDwhichforwardsdatapacket
isVLAN100,congureSVLANbasedonACLandcongure
