Chapter8ZESRandSVLANLinkageNetworkingConguration
gei_1/2asauxiliaryloopbackport.Thedetailedconguration
isasfollows:
ZXR10(config)#vlanqinqextend-session-no1customer-port
gei_1/1uplink-portgei_1/2in-vlan10ovlan100unredirect
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#switchportqinqcustomer
ZXR10(config-gei_1/1)#switchportmodehybrid
ZXR10(config-gei_1/1)#switchporthybridnativevlan10
ZXR10(config-gei_1/1)#switchporthybridvlan10,100untag
ZXR10(config-gei_1/1)#exit
ZXR10(config)#interfacegei_1/2
ZXR10(config-gei_1/2)#switchportmodetrunk
ZXR10(config-gei_1/2)#switchporttrunknativevlan100
ZXR10(config-gei_1/2)#switchporttrunkvlan100
ZXR10(config-gei_1/2)#exit
ZXR10(config)#interfacegei_1/3
ZXR10(config-gei_1/3)#switchportmodetrunk
ZXR10(config-gei_1/3)#switchporttrunknativevlan100
ZXR10(config-gei_1/3)#switchporttrunkvlan100
ZXR10(config-gei_1/3)#exit
ZXR10(config)#interfacegei_1/4
ZXR10(config-gei_1/4)#switchportmodetrunk
ZXR10(config-gei_1/4)#switchporttrunknativevlan100
ZXR10(config-gei_1/4)#switchporttrunkvlan100
ZXR10(config-gei_1/4)#exit
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#mac-duplicate0src-vlan10dest-vlan100
ZXR10(config-gei_1/1)#exit
ZXR10(config)#interfacegei_1/2
ZXR10(config-gei_1/2)#loopbackenable
ZXR10(config-gei_1/2)#exit
ZXR10(config)#vlanprivate-map-unidirectionalsession-id1
sourcegei_1/3-4destinationgei_1/2
ZXR10(config)#vlanprivate-map-unidirectionalsession-id2
sourcegei_1/2destinationgei_1/1
2.Conguregei_1/1ascustomerportontheswitch,theCVID
whichreceivesdatapacketisVLAN10,conguregei_1/3and
gei_1/4asuplinkport,theSPVIDwhichforwardsdatapacket
isVLAN100,congureSVLANbasedonVLANtranslation.The
detailedcongurationisasfollows:
ZXR10(config)#vlanqinqsession-no1customer-port
gei_1/1uplink-portgei_1/3in-vlan10ovlan100
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#switchportqinqcustomer
ZXR10(config-gei_1/1)#switchportmodehybrid
ZXR10(config-gei_1/1)#switchporthybridnativevlan10
ZXR10(config-gei_1/1)#switchporthybridvlan10,100untag
ZXR10(config-gei_1/1)#exit
ZXR10(config)#interfacegei_1/3
ZXR10(config-gei_1/3)#switchportmodetrunk
ZXR10(config-gei_1/3)#switchporttrunknativevlan100
ZXR10(config-gei_1/3)#switchporttrunkvlan100
ZXR10(config-gei_1/3)#exit
ZXR10(config)#interfacegei_1/4
ZXR10(config-gei_1/4)#switchportmodetrunk
ZXR10(config-gei_1/4)#switchporttrunknativevlan100
ZXR10(config-gei_1/4)#switchporttrunkvlan100
ZXR10(config-gei_1/4)#exit
