Chapter1VLANConguration
Wheningresslteringisenabledonaport,theportdropsare-
ceivedframeiftheVLANtowhichtheframebelongsdoesnot
includetheingress.Bydefault,VLANingresslteringisenable.
SettingFrameFilteringTypeofaPort
Tosetframelteringtypeofaport,usethefollowingcommand.
CommandFunction
ZXR10(config-gei_1/x)#acceptableframetypes{all|tag}Thissetsframelteringtypeof
aport.
Thissetstheframetypeoftheportwhichcanreceivealltypes
offramesincludinguntaggedandtaggedframes.Bydefault,all
framesarereceived.
CreatingVLANLayer3Interface
CommandFunction
ZXR10(config)#interface{vlan<vlan-id>|<vlan-if>}
ThiscreatesVLANlayer3
interface.
ItisnecessarytocreatethisVLANbeforecreatingVLANlayer3
interface.
VLANConfigurationExample
Theportsgei_1/1andgei_1/2onSwitchA,andtheportsgei_1/1
andgei_1/2onswitchB,belongtoVLAN10;theportsgei_1/4
andgei_1/5onswitchA,andtheportsgei_1/4andgei_1/5on
switchB,belongtoVLAN20.Thefourportsareallaccessports,
asshowninFigure3.SwitchesAandBareconnectedthrough
portsgei_1/24(twotrunkports)overatrunklink.
FIGURE3VLANNETWORKING
