ZXR105900ESeriesUserManual(EthernetSwitchingVolume)
ZXR10(config)#vlanqinqextend-session-no1customer-port
gei_1/1uplink-portgei_1/2in-vlan10outer-vlan100ovlan200
ZXR10(config)#vlanqinqextend-session-no2customer-portgei_1/1
uplink-portgei_1/2outer-vlan101ovlan201unredirect
TheSVLANexampleofviewingconguration:
ZXR10(config)#showvlanqinqextend-session
SessionCustomerUplinkIn_VlanOuter-vlanOvlanHelpvlan
Priorityunredirect
-----------------------------------------------------------
1gei_1/1gei_1/210100200
2gei_1/1gei_1/2101201
1
TransparentTransmissionSVLAN
Configuration
Example1:singletagtransparenttransmission,port1iscustomer
port.Port2isuplinkport,forthemessagefromport1:when
CVLANis10,transmittedtransparently,helpervlanis100.
ZXR10(config)#switchportgei_1/1qinqcustomer
ZXR10(config)#interfacegei_1/2
ZXR10(config-if)#switchportmodehybrid
ZXR10(config-if)#switchporthybridvlan100untag
ZXR10(config-if)#exit
ZZXR10(config)#vlanqinqextend-session-no1customer-portgei_1/1
uplink-portgei_1/2in-vlan10helpvlan100
TheSVLANexampleofviewingcongurationisasfollows.
ZXR10(config)#showvlanqinqextend-session1
SessionCustomerUplinkIn_VlanOuter-vlanOvlanHelpvlan
Priorityunredirect
-----------------------------------------------------------
1gei_1/1gei_1/210100
Example2:doubletagstransparenttransmission,port1iscus-
tomerport,port2isuplinkport,forthemessagefromport1:
whenCVLANis10andoutertagis100,transmittedtransparently,
helpervlanis100.
ZXR10(config)#interfacegei_1/2
ZXR10(config-if)#switchportmodehybrid
ZXR10(config-if)#switchporthybridvlan100tag
ZXR10(config-if)#exit
ZZXR10(config)#vlanqinqextend-session-no1customer-portgei_1/1
uplink-portgei_1/2in-vlan10outer-vlan100helpvlan100
TheSVLANexampleofviewingcongurationisasfollows.
ZXR10(config)#showvlanqinqextend-session1
SessionCustomerUplinkIn_VlanOuter-vlanOvlanHelpvlan
Priorityunredirect
-----------------------------------------------------------
1gei_1/1gei_1/210100100
