Chapter14EthernetOAMConguration
00d0.d052.1200
ThecongurationsofS2areasfollows:
ZXR10(config)#interfacegei_2/1
ZXR10(config－gei_2/1)#switchmodetrunk
ZXR10(config－gei_2/1)#exit
ZXR10(config)#interfacegei_2/2
ZXR10(config－gei_2/2)#switchmodetrunk
ZXR10(config－gei_2/2)#exit
ZXR10(config)#vlan10
ZXR10(config-vlan10)#switchporttaggei_2/1
ZXR10(config-vlan10)#switchporttaggei_2/2
ZXR10(config-vlan10)#exit
ZXR10(config)#cfmcreatemdsession15namemd15level7
ZXR10(config-md)#macreatesession32namema1
ZXR10(config-md-ma)#protectvlan
ZXR10(config-md-ma)#primaryvlan10
ZXR10(config-md-ma)#speedslow
ZXR10(config-md-ma)#createmipsession63namemip63
ZXR10(config-md-ma)#assignmip63interfacegei_2/1
ZXR10(config)#cfmenable
ThecongurationsofS3areasfollows:
ZXR10(config)#interfacegei_3/1
ZXR10(config－gei_3/1)#switchmodetrunk
ZXR10(config－gei_3/1)#exit
ZXR10(config)#vlan10
ZXR10(config-vlan10)#switchporttaggei_3/1
ZXR10(config-vlan10)#exit
ZXR10(config)#cfmcreatemdsession15namemd15level7
ZXR10(config-md)#macreatesession32namema1
ZXR10(config-md-ma)#protectvlan
ZXR10(config-md-ma)#primaryvlan10
ZXR10(config-md-ma)#speedslow
ZXR10(config-md-ma)#createmepsession622directiondown
ZXR10(config-md-ma)#assignmep2tointerfacegei_3/1
ZXR10(config-md-ma)#mep2stateenable
ZXR10(config-md-ma)#creatermepsession21remote-mac
00d0.d052.2800
ZXR10(config)#cfmenable
ToenableLTfunctiononS1,usethefollowingcommand.
ZXR10#cfmltmmd15ma32smep-id1dmep-id2
InterfacethatS1viewsisasfollows:
Linktraceto00d0.d052.2800:timeout5seconds,64hops,trans-id1.
Pleasewait5secondstoprinttheresult.
---------------------------------------------------------------
HopsMACADDRESSIngressActionEgressActionRelayAction
---------------------------------------------------------------
100d0.d034.5670EgrOKRlyFDB
200d0.d052.2800IngOKRlyHit
Destination00d0.d052.2800reached.
