Chapter7ZESSConguration
ZXR10_S1(config-gei_1/1)#exit
ZXR10_S1(config)#interfacegei_1/2
ZXR10_S1(config-gei_1/2)#negotiationauto
ZXR10_S1(config-gei_1/2)#switchportmodetrunk
ZXR10_S1(config-gei_1/2)#switchporttrunkvlan100-200
ZXR10_S1(config-gei_1/2)#switchporttrunkvlan4000
ZXR10_S1(config-gei_1/2)#smartgroup1modeactive
ZXR10_S1(config-gei_1/2)#spanning-treedisable
ZXR10_S1(config-gei_1/2)#exit
ZXR10_S1(config)#interfacegei_1/3
ZXR10_S1(config-gei_1/3)#negotiationauto
ZXR10_S1(config-gei_1/3)#switchportmodetrunk
ZXR10_S1(config-gei_1/3)#switchporttrunkvlan100-200
ZXR10_S1(config-gei_1/3)#switchporttrunkvlan4000
ZXR10_S1(config-gei_1/3)#smartgroup2modeactiv
ZXR10_S1(config-gei_1/3)#spanning-treedisable
ZXR10_S1(config-gei_1/3)#exit
ZXR10_S1(config)#interfacegei_1/4
ZXR10_S1(config-gei_1/4)#negotiationauto
ZXR10_S1(config-gei_1/4)#switchportmodetrunk
ZXR10_S1(config-gei_1/4)#switchporttrunkvlan100-200
ZXR10_S1(config-gei_1/4)#switchporttrunkvlan4000
ZXR10_S1(config-gei_1/4)#smartgroup2modeactive
ZXR10_S1(config-gei_1/4)#spanning-treedisable
ZXR10_S1(config-gei_1/4)#exit
ZXR10_S1(config)#zessdoamin1protect-instance1
primarysmartgroup1secondarysmartgroup2
ZXR10_S1(config)#zessdomain1ctl-vlan4000
Node2conguration:
ZXR10_S2(config)#spanning-treeenable
ZXR10_S2(config)#spanning-treemstconfiguration
ZXR10(config-mstp)#instance1vlan100-200
ZXR10(config-mstp)#exit
ZXR10_S2(config)#interfacesmartgroup1
ZXR10_S2(config-smartgroup1)switchportmodetrunk
ZXR10_S2(config-smartgroup1)#smartgroupmode802.3ad
ZXR10_S2(config-smartgroup1)switchporttrunkvlan100-200
ZXR10_S2(config-smartgroup1)switchporttrunkvlan4000
ZXR10_S2(config-smartgroup1)exit
ZXR10_S2(config)#interfacegei_1/1
ZXR10_S2(config-gei_1/1)switchportmodetrunk
ZXR10_S2(config-gei_1/1)switchporttrunkvlan100-200
ZXR10_S2(config-gei_1/1)switchporttrunkvlan4000
ZXR10_S2(config-gei_1/1)exit
ZXR10_S2(config)#interfacegei_1/3
ZXR10_S2(config-gei_1/3)negotiationauto
ZXR10_S2(config-gei_1/3)switchportmodetrunk
ZXR10_S2(config-gei_1/3)switchporttrunkvlan100-200
ZXR10_S2(config-gei_1/3)switchporttrunkvlan4000
ZXR10_S2(config-gei_1/3)smartgroup1modeactive
ZXR10_S2(config-gei_1/3)spanning-treedisable
ZXR10_S2(config-gei_1/3)exit
ZXR10_S2(config)#interfacegei_1/4
ZXR10_S2(config-gei_1/4)negotiationauto
ZXR10_S2(config-gei_1/4)switchportmodetrunk
ZXR10_S2(config-gei_1/4)switchporttrunkvlan100-200
ZXR10_S2(config-gei_1/4)switchporttrunkvlan4000
ZXR10_S2(config-gei_1/4)smartgroup1modeactive
ZXR10_S2(config-gei_1/4)spanning-treedisable
ZXR10_S2(config-gei_1/4)exit
ZXR10_S2(config)#interfacesmartgroup1
ZXR10_S2(config-smartgroup1)#zessreceive-vlan4000
ZXR10_S2(config)#interfacegei_1/1
