Zybio Z3 Service Manual

1
1 Using This Manual
1.1 Overview
This chapter describes how to use the service manual. In this manual, the repair methods of Z3
are described in detail. Before servicing Z3, please carefully read and understand the content in
order to properly carry out maintenance procedures and ensure the safety of service personnel.
This manual must be used in conjunction with the Z3 Operator’s manual. It does not contain
information and procedures already covered in the Operator’s manual of Z3.
Be sure to operate and service the analyzer strictly as instructed in
this manual and the operator’s manual.
1.2 Who Should Read This Manual
This manual is intended to be read by service professionals who:
 Have comprehensive knowledge of circuitry and fluidics;
 Have comprehensive knowledge of reagents;
 Have comprehensive knowledge of quality control;
 Have comprehensive knowledge of troubleshooting;
 Are familiar with the operations of the system;
 Are able to use basic mechanical tools and understand the terminology;
 Are skilled users of the digital voltmeter and oscillograph;
 Are able to analyze the circuit diagrams and fluidic charts.
1.3 Conventions Used in This Manual
This manual uses certain typographical conventions to clarify meaning in the text:
Format
Meaning
[××]
all capital letters enclosed in [ ] indicate a key name (either on
the pop-up keyboard or the external keyboard)
“××”
letters included in " " indicate text you can find on the screen of
Z3
××
italic letters indicate titles of the chapters that are referred to
All illustrations in this manual are provided as examples only. They may not necessarily reflect your
analyzer setup or data displayed.
