Setting up One-to-One NAT
119
.
You cannot include the NAT Public IP Address in a range.
Click
Advanced
, and then select the
One-to-One NAT
tab.
A window similar to that in Figure 51
is displayed.
Figure 51
One-to-One NAT Window
Table 4
Address Correspondence in One-to-One NAT
LAN Address Corresponding WAN Address Accessed Through
192.168.1.1 209.19.28.16 Inaccessible: NAT Public IP
Address
192.168.1.2 209.19.28.17 Accessed at 209.19.28.17
[...] [...] [...]
192.168.1.16 209.19.28.31 Accessed at 209.19.28.31
192.168.1.33 No corresponding valid IP
address
Inaccessible except as Public
LAN Server
[...] [...] [...]
192.168.1.255 No corresponding valid IP
address
Inaccessible except as Public
LAN Server
