A
C
ABLE
S
PECIFICATIONS
AND
P
INOUT
D
IAGRAM
This appendix contains the following:
■
Cable Specifications
■
Pinout Diagrams
Cable Specifications
The OfficeConnect
®
Internet Firewall supports the
following cable types and maximum lengths:
■
10BASE-T Twisted Pair
■
Maximum cable length of 100 m (327.86 ft).
Pinout Diagrams
Tabl e 5 shows the pinouts connections for RJ-45.
Figure 52
shows the pinout connections for twisted pair
cable.
Table 5
RJ-45 Pinouts
Pin Function
1 RD+
2 RD –
3 TD +
4
5
6 TD –
7
8
