133D Systems, Inc.
16. Align the jet wiper assembly bottom tab (A) with the slot in the oor (B) and slide
the jet wiper assembly downward.
NOTE: If the jet wiper assembly is fully seated into the keyhole
slots but the bottom does not rest on the thumbscrew head, remove
the jet wiper and turn the thumbscrew counter-clockwise until the
jet wiper bottom rests on the thumbscrew head and the keyhole
slots are fully seated. This may require repeated removals and
re-installations of the jet wiper. If the keyhole slots will not seat,
the thumbscrew may need to be adjusted downward by turning
clockwise.
NOTE: Refer to the section titled Adjusting the Jet Wiper Assembly
for information about adjusting the jet wiper scraper height.
17. Remove the print pad from the box and place it onto the print platform with the
round magnet on the bottom of the pad inserted into the triangular opening on
the platform. Ensure the print pad is securely seated on the print plate.
18. Connect the power cord to the power inlet port (B) on the right side of the printer
and the other end to a wall outlet. Press the power on/off switch (A) to power on
the CubePro.
19. Press the on/off button (A) beside the LED screen to power on the CubePro
touchscreen display.
20. Press the touchscreen to navigate to the main menu.
NOTE: Turning on the touchscreen will also turn on the interior LED
lights.
A
A
B
A
B
