6. If the wiper blade is too high, remove the jet wiper assembly and turn the
adjustment thumbscrew (A) clockwise. Reinstall the jet wiper and return to step
5.
7. If the wiper tip is too low, remove the jet wiper assembly and turn the
adjustment thumbscrew (A) counter-clockwise. Reinstall the jet wiper and return
to step 5.
8. Once satised with the adjustment, you may connect your printer to utility power
and power on the printer.
A
A
