4IPNET EAP210 - EAP760 Hardware Description

User’s Manual
Enterprise Access Point ENGLISH
Copyright © 4IPNET, INC. All rights reserved.
28
EAP760
Front View
1a
2
1b 1c
EAP760 Front View
1
External Antenna
External antennas via SMA connectors. 1a, 1b and 1c corresponds to
Ant1, Ant2 and Ant3 of the system.
2
LED Indicator
An LED indicator is available to show the uplink status.
