Operation Manual / 4 Product description / A130-M.. - A145-M..

8 Dismantling and fitting / 8.7 Pressing off the casing

8.7 Pressing off the casing

CAUTION

Axial force of the press-off tool

Using the press-off tool (90042), a high level of axial force can be generated.

If the casing is pressed off with too much force on one side, the rotor can be

damaged.

u Use the tool on both sides in alternation and make sure not to press off

too hard on either side.

Fig.36: Press off the casing

Page 79 / 111
