Operation Manual / 4 Product description / A130-M.. - A145-M..

5 Operation and service / 5.2 Service work

5.2.5 Other service work

If a protective grid is installed in the gas outlet casing (61001) by ABB Turbo Systems:

Fig.21: Replacing the protective grid

u Remove the protective grid (61205) after 50000 hours and replace it with a new protect-

ive grid.

Page 35 / 111
