Operation Manual / 4 Product description / A130-M.. - A145-M..

8 Dismantling and fitting / 8.1 Introduction

Two ring nuts are required for safer lifting of the cartridge group, which are not included in

the ABB Turbo Systems scope of delivery.

Ring nuts to be used (VRM) Product Thread

Starpoint ring nut VRM

A130 M16

A135 M16

A140 M16

A145 M16

Table34: Ring nuts to be used

Page 69 / 111
