ABB ACS150 User Manual

Actual signals and parameters
98
0, x…x Parameter index in group 01 OPERATING DATA. E.g. 102 = 0101 SPEED.
0 = not selected.
3202 SUPERV 1 LIM LO Defines the low limit for the first supervised signal selected by parameter
3201 SUPERV 1 PARAM. Supervision wakes up if the value is below the
limit.
-
x…x Setting range depends on parameter 3201 setting. -
3203 SUPERV 1 LIM HI Defines the high limit for the first supervised signal selected by parameter
3201 SUPERV 1 PARAM. Supervision wakes up if the value is above the
limit.
-
x…x Setting range depends on parameter 3201 setting. -
3204 SUPERV 2 PARAM Selects the second supervised signal. Supervision limits are defined by
parameters 3205 SUPERV 2 LIM LO and 3206 SUPERV 2 LIM HI. See
parameter 3201 SUPERV 1 PARAM.
104
x…x Parameter index in group 01 OPERATING DATA. E.g. 102 = 0101 SPEED.
3205 SUPERV 2 LIM LO Defines the low limit for the second supervised signal selected by parameter
3204 SUPERV 2 PARAM. Supervision wakes up if the value is below the
limit.
-
x…x Setting range depends on parameter 3204 setting. -
3206 SUPERV 2 LIM HI Defines the high limit for the second supervised signal selected by parameter
3204 SUPERV 2 PARAM. Supervision wakes up if the value is above the
limit.
-
x…x Setting range depends on parameter 3204 setting. -
3207 SUPERV 3 PARAM Selects the third supervised signal. Supervision limits are defined by
parameters 3208 SUPERV 3 LIM LO and 3209 SUPERV 3 LIM HI. See
parameter 3201 SUPERV 1 PARAM.
105
x…x Parameter index in group 01 OPERATING DATA. E.g. 102 = 0101 SPEED.
3208 SUPERV 3 LIM LO Defines the low limit for the third supervised signal selected by parameter
3207 SUPERV 3 PARAM. Supervision wakes up if the value is below the
limit.
-
x…x Setting range depends on parameter 3207 setting. -
3209 SUPERV 3 LIM HI Defines the high limit for the third supervised signal selected by parameter
3207 SUPERV 3 PARAM. Supervision wakes up if the value is above the
limit.
-
x…x Setting range depends on parameter 3207 setting. -
33 INFORMATION
Firmware package version, test date etc.
3301 FIRMWARE Displays the version of the firmware package.
0.0000…FFFF (hex) E.g. 1.30b
3302 LP VERSION Displays the version of the loading package. Type
dependent
0x2001…0x20FF
(hex)
0x2021 = ACS150-0x (Eur GML)
3303 TEST DATE Displays the test date. 00.00
Date value in format YY.WW (year, week)
Parameters in the Long Parameter mode
Index Name/Selection Description Def

ABB ACS150 Specifications

General

Power Range	0.37 to 4 kW
Voltage Range	200 to 240 V, 380 to 480 V
Frequency	50/60 Hz
Control Method	Scalar control
Protection Class	IP20
Frequency Range	0 to 500 Hz
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % (non-condensing)
Ambient Temperature	-10 to +50 °C
I/O	Digital inputs, Analog inputs, Relay outputs
Overload Capacity	150% for 60 seconds
Braking Chopper	Built-in (for some models)
